Poco C75 lake OS1.0.4.0 HyperOS Firmware
Download Poco C75 lake HyperOS 1.0.4.0 stock firmware from RomWala. Based on Android 14. Fix pattern lock- FRP- hang on logo- brick after update. Flash using SP Flash Tool with MTK Bypass. Direct link...
43 views
0 downloads
Available Downloads
Loading files...
Full Specifications
Poco C75 lake OS1.0.4.0 HyperOS Firmware
| Description | Official HyperOS 1.0.4.0 stock firmware flash file for Poco C75 codename lake from RomWala. Based on Android 14. Fix pattern lock- FRP- hang on logo- brick after update- hanging issues. Flash using SP Flash Tool or Mi Flash Tool with MTK Bypass. |
| Device Name | Poco C75 |
| Brand | Xiaomi / Poco |
| Model Numbers | 2409FPCA4G, 2409FPCA4I, 2409FPCA4H |
| Codename | lake |
| Firmware Version | OS1.0.4.0.UGRMIXM / OS1.0.4.0.UGRINXM / OS1.0.4.0.UGRCNXM |
| System | HyperOS 1.0 |
| Android | 14 |
| Chipset | MediaTek Helio G81 Ultra |
| Chipset Manufacturing Process | 12nm |
| CPU | Octa-core (2x2.0GHz Cortex-A75 + 6x1.8GHz Cortex-A55) |
| GPU | ARM Mali-G52 MC2 |
| RAM Options | 4GB-6GB-8GB LPDDR4X |
| Storage Options | 64GB-128GB-256GB eMMC 5.1 |
| Expandable Storage | Yes (microSDXC up to 1TB) |
| Battery Capacity | 5160mAh non-removable |
| Charging Support | 18W fast charging |
| Display | 6.88 inches IPS LCD |
| Display Resolution | 720 x 1640 pixels (HD+) |
| Display Refresh Rate | 120Hz |
| OS | HyperOS 1.0 based on Android 14 |
| Rear Camera | 50MP + 2MP |
| Front Camera | 13MP |
| Fingerprint | Side-mounted |
| Network | 4G LTE Dual SIM |
| Available Versions | Firmware Version: OS1.0.4.0.UGRMIXM Region: Global Android: 14 System: HyperOS 1.0 Firmware Version: OS1.0.4.0.UGRINXM Region: India Android: 14 System: HyperOS 1.0 Firmware Version: OS1.0.4.0.UGRCNXM Region: China Android: 14 System: HyperOS 1.0 |
| What is Included | Full stock firmware package (Scatter file, preloader, boot, system, vendor, userdata, etc.) |
| Important Notes | Note 1: Poco C75 codename lake - MediaTek Helio G81 Ultra platform Note 2: Shares hardware with Redmi 14C (same codename lake) Note 3: Requires MTK Bypass Tool for flashing Note 4: Backup data before flashing Note 5: HyperOS 1.0 based on Android 14 |
| Use Cases | Fix pattern lock, FRP bypass, Hang on logo fix, Brick repair, Boot loop fix, Upgrade and downgrade, Software issues |
| Compatible Tools | SP Flash Tool, MTK Client, MTK Bypass Tool, Octoplus Box, Chimera Tool, Mi Flash Tool |
| How to Flash Using SP Flash Tool | PreRequisites: MediaTek USB VCOM drivers installed, SP Flash Tool, MTK Bypass Tool Step 1: Download and extract firmware package Step 2: Install MediaTek USB VCOM drivers Step 3: Run MTK Bypass Tool to disable SLA/DAA authentication Step 4: Open SP Flash Tool as administrator Step 5: Click 'Scatter-loading' and select scatter.txt from firmware folder Step 6: Select 'Download Only' or 'Format All + Download' mode Step 7: Click 'Download' button Step 8: Power off Poco C75 completely Step 9: Press and hold Volume Up + Volume Down buttons together Step 10: Connect USB cable while holding both keys Step 11: Device enters BROM mode (screen stays black) Step 12: SP Flash Tool will detect device automatically Step 13: Flashing starts automatically - purple progress bar Step 14: Wait for green checkmark 'Download OK' message Step 15: Disconnect USB cable and power on device Step 16: First boot takes 3-5 minutes |
| How to Flash Using Mi Flash Tool | PreRequisites: Unlocked bootloader required for Fastboot method Step 1: Extract firmware (tgz format) to a folder Step 2: Boot Poco C75 into Fastboot mode (Volume Down + Power) Step 3: Launch Mi Flash Tool as administrator Step 4: Click 'Select' and choose the extracted firmware folder Step 5: Select 'Clean All' mode Step 6: Click 'Flash' button Step 7: Wait for completion Step 8: Device will reboot automatically |
| How to Enter BROM Mode | Method 1 - Key Combo: Power off, press Volume Up + Volume Down, connect USB Method 2 - Test Points: Short test points on motherboard (if key combo fails) |
| PreRequisites | 70 percent battery, Original USB cable, MediaTek USB VCOM drivers, SP Flash Tool, MTK Bypass Tool, Windows PC, Backup before flash |
| Advantages | Unbrick device, Fix boot loop, Upgrade and downgrade, Unroot and fix bugs, Fix lag or stutter, Solve software problems, Revert to Stock to gain warranty |
| Purpose | Pattern unlock, FRP bypass, Hang on logo fix, Brick repair, Boot loop fix |
| Flash Tools | SP Flash Tool, Mi Flash Tool, MTK Client |
| Flash Mode | BROM mode (key combo) or Fastboot mode |
| Requirements | 70 percent battery, USB cable, MediaTek drivers, Windows PC, Backup before flash |
| Warnings | Use on Poco C75 lake only, Do not disconnect during flashing, All user data erased, Use MTK Bypass Tool for newer security, All operations at your own risk |
| Troubleshooting | Device not detected - reinstall MediaTek drivers, Auth error - use MTK Bypass Tool, BROM mode not entering - try test points, Flashing fails - try different USB port, Device stuck - perform factory reset from recovery |
Poco C75 lake OS1.0.4.0 HyperOS Firmware - Description
Download Poco C75 lake HyperOS 1.0.4.0 stock firmware from RomWala. Based on Android 14. Fix pattern lock- FRP- hang on logo- brick after update. Flash using SP Flash Tool with MTK Bypass. Direct link below.
